Mini Brass 90˚ Needle Valve with an inlet of 1/8” male threads. Outlet sizes are female 10-32 threads, male 10-32 threads or 1/16”, 1/8” and 3/32” barbs. Available seals are Buna-N, EPDM and Viton®. The maximum operating pressure is 125 psi, maximum operating temperature is 180˚ F. Panel mount is standard. This Needle Valve is also available with female 10-32 UNF inlet and outlet threads. The barb sizes are the same as for the male Needle Valve. The black ABS knobs are standard, removable knobs.
SPNV Series
Description
| SKU | Description |
|---|---|
| SPNV-10F10F | 10-32F by 10-32F Needle Valve |
| SPNV-2M10F | 1/8 MNPT In by 10-32 Female Out Needle Valve |
| SPNV-2M1B | 1/8 MNPT In by 1/16 Barb Out Needle Valve |
| SPNV-10F2B | 10-32 Female UNF In by 1/8 Barb Out Needle |
